Aviation Obstruction Lights
request a quote
Part No.
Description
Lamp Used
JBI 901
Single Aviation Obstruction Light of incandescent lamp, die-cast aluminum alloy housing with polycarbonate dome.
GLS 60 - 100W
request a quote
Part No.
Description
Lamp Used
JBI 902
Double Aviation Obstruction Light of incandescent lamp, die-cast aluminum alloy housing with polycarbonate dome.
2 X GLS 60 - 100W
request a quote
Part No.
Description
Lamp Used
JBI 903
Single Aviation Obstruction Light of Neon Spiral, with built in 75VA Step up transformer, die-cast aluminum alloy housing, Heat Resistant, Clear thick glass & Accessories.
75 VA Neon Spiral
request a quote
Part No.
Description
Lamp Used
JBI 904
LED Single Aviation Obstruction Light, die-cast aluminum alloy housing with Polycarbonate Dome.
LED’s System
Salient Features
Gives omni directional light
Protection: Weather proof IP 55
Material of construction: Cast aluminum (LM 6)
Transparent part: Polycarbonate glass Dome
Gasket: Neoprene.
Light source: High power light emitting diodes, mounted on glass epoxy Fire Retarded PCBs
Operates directly on 230V/50Hz ac, can withstand high voltage fluctuations.
Multiple light elements reduce chances of complete blackout due to any unlikely lamp failure
Approx life of around 100000 hrs
No. Of LEDs: 300 nos.
Luminous Intensity: 10-35 Cd
Earthing Terminal: Provided.
Paint: Aviation Yellow (Epoxy Powder Coated)
Optional: Flashing / Inbuilt photo sensor for automatic control.
request a quote
Part No.
Description
Lamp Used
JBI 905
LED Double Aviation Obstruction Light, die-cast aluminum alloy housing with Polycarbonate Dome.
2 X LED’s System
Salient Features
Gives omni directional light
Protection: Weather proof IP 55
Material of construction: Cast aluminum (LM 6)
Transparent part: Polycarbonate RED glass Dome
Gasket: Neoprene.
Light source: High power light emitting diodes, mounted on glass epoxy PCBs
Operates directly on 230V/50Hz ac, can withstand high voltage fluctuations.
Multiple light elements reduce chances of complete blackout due to any unlikely lamp failure.
Approx life of around 100000 hrs ¨ No. Of LEDs: 600 nos.
In an unlikely situation of one complete LED lamp cluster failure the other continues to work.
Operates directly on 230V/50Hz ac.
Installation by means of a 38 mm E.T. stem.
Earthing Terminal: Provided.
Paint: Aviation Yellow (Epoxy Powder Coated)
